DG12000LN

Technical Parameter
Rated frequency [Hz]	50	60
Rated power [kw]	8.0	9.6
Max. power [kw]	8.8	10.5
Phase	Single phase
DC output	12V/8.3A
Power factor [cosφ]	1.0
Noise level [dB(A)@7m]	≤80
Net weight [kg]	181
Gross weight [kg]	191
Dimension (LxWxH) [mm]	1200x640x920
Engine model	LD812D
Engine type	V-twin, 4-stroke, air-cooled
Max. power [kw]	11.76X	14.7
Max.speed [r/min]	3000	3600
Max. torque [N.m/r/min]	48/2400
Fuel consumption [g/kw.h]	298
Displacement [ml]	812
Lube oil capacity [L]	1.7
Noise level [dB(A)@7m]	≤84
Rotating direction at output end	Counter-clockwise
Net weight [kg]	56
Gross weight [kg]	75
Dimension (LxWxH) [mm]	525x391x459
Starting system	Electric starter
